GraphQL Voyager

Represent any GraphQL API as an interactive graph. It's time to finally see the graph behind GraphQL. You can also explore number of public GraphQL APIs from our list.

With graphql-voyager you can visually explore your GraphQL API as an interactive graph. This is a great tool when designing or discussing your data model. It includes multiple example GraphQL schemas and also allows you to connect it to your own GraphQL endpoint. What are you waiting for, explore your API!

GraphQL Weekly #42

Live Demo

Features

Quick navigation on graph
Left panel which provides more detailed information about every type
"Skip Relay" option that simplifies graph by removing Relay wrapper classes
Ability to choose any type to be a root of the graph

API

GraphQL Voyager exports Voyager React component and helper init function. If used without module system it is exported as GraphQLVoyager global variable.

Properties

Voyager component accepts the following properties:

introspection [object] - the server introspection response. If function is provided GraphQL Voyager will pass introspection query as a first function parameter. Function should return Promise which resolves to introspection response object.
displayOptions (optional)
- displayOptions.skipRelay [boolean, default true] - skip relay-related entities
- displayOptions.skipDeprecated [boolean, default true] - skip deprecated fields and entities that contain only deprecated fields.
- displayOptions.rootType [string] - name of the type to be used as a root
- displayOptions.sortByAlphabet [boolean, default false] - sort fields on graph by alphabet
- displayOptions.showLeafFields [boolean, default true] - show all scalars and enums
- displayOptions.hideRoot [boolean, default false] - hide the root type
allowToChangeSchema [boolean, default false] - allow users to change schema
hideDocs [boolean, default false] - hide the docs sidebar
hideSettings [boolean, default false] - hide settings panel
hideVoyagerLogo [boolean, default true] - hide voyager logo

Using pre-bundled version

You can get GraphQL Voyager bundle from the following places:

- some exact version - https://cdn.jsdelivr.net/npm/graphql-voyager@1.3/dist/voyager.standalone.js
- latest version - https://cdn.jsdelivr.net/npm/graphql-voyager/dist/voyager.standalone.js
from dist folder of the npm package graphql-voyager

Note: voyager.standalone.js is bundled with react, so you just need to call renderVoyager function that's it.

HTML example

Using as a dependency

Build for the web with webpack, or any other bundle.

Webpack example

Middleware

GraphQL Voyager has middleware for the next frameworks:

Properties

Middleware supports the following properties:

endpointUrl [string] - the GraphQL endpoint url.
displayOptions [object] - same as here
headersJS [string, default "{}"] - object of headers serialized in string to be used on endpoint url
Note: You can also use any JS expression which results in an object with header names as keys and strings as values e.g. { Authorization: localStorage['Meteor.loginToken'] }

Express

import express from 'express';
import { express as voyagerMiddleware } from 'graphql-voyager/middleware';

const app = express();

app.use('/voyager', voyagerMiddleware({ endpointUrl: '/graphql' }));

app.listen(3001);

Hapi

Version 20+

import Hapi from '@hapi/hapi';
import { hapi as voyagerMiddleware } from 'graphql-voyager/middleware';

const server = new Hapi.Server({
  port: 3001,
});

const init = async () => {
  await server.register({
    plugin: voyagerMiddleware,
    options: {
      path: '/voyager',
      endpointUrl: '/graphql',
    },
  });

  await server.start();
};

init();

Koa

import Koa from 'koa';
import KoaRouter from 'koa-router';
import { koa as voyagerMiddleware } from 'graphql-voyager/middleware';

const app = new Koa();
const router = new KoaRouter();

router.all(
  '/voyager',
  voyagerMiddleware({
    endpointUrl: '/graphql',
  }),
);

app.use(router.routes());
app.use(router.allowedMethods());
app.listen(3001);

Credits

This tool is inspired by graphql-visualizer project.

This project is tested with BrowserStack.
